TYPE
|
DESCRIPTION
|
|---|---|
|
Category
|
Inductors, Coils, Chokes
Fixed Inductors
|
|
Mfr
|
TDK Corporation
|
|
Series
|
NLV-PF
|
|
Package
|
Tape & Reel
|
|
Product Status
|
Not For New Designs
|
|
Type
|
Drum Core, Wirewound
|
|
Material - Core
|
Ferrite
|
|
Inductance
|
1.5 µH
|
|
Tolerance
|
±5%
|
|
Current Rating (Amps)
|
370 mA
|
|
Current - Saturation (Isat)
|
-
|
|
Shielding
|
Unshielded
|
|
DC Resistance (DCR)
|
850mOhm Max
|
|
Q @ Freq
|
30 @ 7.96MHz
|
|
Frequency - Self Resonant
|
85MHz
|
|
Ratings
|
-
|
|
Operating Temperature
|
-40°C ~ 105°C
|
|
Inductance Frequency - Test
|
7.96 MHz
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
1210 (3225 Metric)
|
|
Supplier Device Package
|
1210
|
|
Size / Dimension
|
0.126" L x 0.098" W (3.20mm x 2.50mm)
|
|
Height - Seated (Max)
|
0.094" (2.40mm)
|
